2024 Husqvarna EE 5

Redefining Motocross

Starting at $5,699

Electric motor

Producing a peak power output of 5 kW, the performance from the EE 5 electric motor is on par with its combustion counterparts. Engineered to be extremely compact and slim, the permanent magnet, air-cooled motor is designed specifically for the EE 5 chassis. The motor is both water and dust proof, which means it is largely maintenance free. With an Electronic Control Unit (ECU), power is delivered directly to the rear wheel and can be further customised by selecting one of six different ride modes.

ENGINE
RATED OUTPUT 2 kW / 3,200 rpm
TORQUE 13.8 Nm
TRACTION BATTERY Lithium-ion
BATTERY CAPACITY 21 Ah
CHARGER LINE VOLTAGE 80-240 V/50-60 Hz
CHARGING INPUT
Quick charging 5 A @ 230 V (AC)
CHARGING POWER 900 W
CHARGING TIME 100 % 70 min.
CHARGING TIME 80 % 45 min.
COOLING Air cooled
ELECTRIC MOTOR
48 V – BLDC motor with outer rotor
6000 rpm
MAX. POWER 5 kW / 3,900 rpm
CHASSIS
WEIGHT (WITHOUT FUEL) 40.5 kg
FRONT BRAKE DISC DIAMETER 205 mm
REAR BRAKE DISC DIAMETER 185 mm
FRONT BRAKE Disc brake
REAR BRAKE Disc brake
CHAIN 1/2 x 3/16″
FRAME DESIGN
Chrome-molybdenum steel central-tube frame
FRONT SUSPENSION
WP-USD, AER 35, Ø 35 mm
GROUND CLEARANCE 252 mm
REAR SUSPENSION XACT WP mono shock
SEAT HEIGHT 665/615 mm
STEERING HEAD ANGLE 66 °
SUSPENSION TRAVEL (FRONT) 205 mm
SUSPENSION TRAVEL (REAR) 185 mm
